Search found 38 matches

by Sari
04 Jun 2022, 03:48
Forum: Modern Stompbox Effects (1975 - ...)
Topic: Dunlop gcb95 resistor specs preference?
Replies: 5
Views: 659

Re: Dunlop gcb95 resistor specs preference?

Good on you for going DIY :)

If you are up for it, using a 50k trimmer or potentiometer in series with a 22k resistor would give you the ability to tune the exact input level desired.
by Sari
27 Feb 2015, 17:28
Forum: Printed/Published Online Designs
Topic: Marshall Drivemaster Mod (KOT + Aefa Drive)
Replies: 1
Views: 2676

Re: Marshall Drivemaster Mod (KOT + Aefa Drive)

The mods are in red, I'm unsure if the soft clipping in the first stage will work properly.. Yes, since the second stage is actively boosting the voltage seen on it's input it wont be a problem. Tone-wise it might be too compressed or even redundant, but it is really a matter of personal taste. As ...
by Sari
16 Mar 2014, 18:11
Forum: Modern Stompbox Effects (1975 - ...)
Topic: Voodoo Lab - Giggity [gutshots]
Replies: 10
Views: 11858

Re: Voodoo Lab - Giggity [gutshots]

Here is my guess, based on the gut pictures and description form the company: 1. Input gain stage similar to DOD250 or MXR D+ : uses a reverse log taper as a variable resistor between the inverting input of an OA stage and a capacitor to ground or reference, so that you have a "fat" tone a...
by Sari
21 Feb 2013, 20:39
Forum: Boutique Stompboxes dissected...
Topic: 65 Amps - Colour Boost [traced]
Replies: 10
Views: 4347

Re: 65 Amps - Colour Boost [traced]

Hi folks I made a mistake and refused to trade a Colour Boost in a trade... and now it's sold... and I want it so bad that I am looking for schematics / pics / any infos that could give me enough informations to build it with its very efficient tone control. Many thanks Thomas Hi Thomas, Use this s...
by Sari
11 Jan 2013, 13:21
Forum: Davidoff Library
Topic: Guitar stencils project
Replies: 2
Views: 7083

Re: Guitar stencils project

Awesome!

Thanks :)
by Sari
04 Jul 2012, 13:01
Forum: Boutique Stompboxes dissected...
Topic: Dwarfcraft devices - Robot Devil
Replies: 35
Views: 16039

Re: Dwarfcraft devices - Robot Devil

Something along these lines?


...perhaps :)
by Sari
23 Mar 2012, 07:55
Forum: Boutique Stompboxes dissected...
Topic: Providence Stampede OD SOV-2 [traced]
Replies: 21
Views: 10995

Re: Providence Stampede OD SOV-2 [traced]

This is a +/-15V circuit. 9V is dropped to 5V on the SUB PCB by a TA78L005 3-pin regulator and then stepped up to +/-15V with a muRata NMA0515SC DC-converter. There's a cheaper way to obtain a +/-15V from a single 9V supply? Maybe using LT1044 or LT1054? Actually there is! Check the data sheet - th...
by Sari
02 Aug 2011, 22:39
Forum: Announcements and Forum Rules
Topic: Important: boutique sections closed... DMCA kicks in.
Replies: 308
Views: 167285

Re: Important: boutique sections closed... DMCA kicks in.

This is a righteous fight! Bless you guys :)
by Sari
11 May 2011, 21:58
Forum: Boutique Stompboxes dissected...
Topic: Fulltone - Plimsoul [traced]
Replies: 54
Views: 32478

Re: Fulltone Plimsoul [traced]

Seiche wrote:that high cut pot is pretty fancy too, possibly custom made?

so what've we got here? led clippers for the hard clipping and 3 silicon diodes for the soft?
It's the secret pot - the "Super Cute"... all SMD parts inside make it really nice sounding :wink:
by Sari
08 May 2011, 19:39
Forum: Boutique Stompboxes dissected...
Topic: Catalinbread - Manx Loaghtan [traced]
Replies: 86
Views: 27631

Re: Catalinbread Manx Loaghtan [guts] [traced]

atreidesheir wrote:No matter what it is, it is a fugly enclosure.
Well, it is a fugly beast...
by Sari
28 Apr 2011, 12:17
Forum: Boutique Stompboxes dissected...
Topic: Death By Audio - Robot [traced]
Replies: 176
Views: 68846

Re: Death By Audio - Robot [traced]

Regarding the schematic in this thread.... Does the Robot actually have switches on pins 1-3? Seems like all the functions are handled by pins 15-18. That rotary switch diagram makes no sense to me. It's explained in the datasheet of the chip. Either you use the rotary switch as done in the DBA Rob...
by Sari
21 Mar 2011, 00:12
Forum: Boutique Stompboxes dissected...
Topic: Mad Professor Sweet Honey Overdrive [traced]
Replies: 124
Views: 78740

Re: Mad Professor Sweet Honey Overdrive [traced]

Cerberus wrote:Just curious, what does the 5.1 zener and 1k resistor do before the led, just a current limiter?, never seen that done before.

Been done on most Boss and Ibanez pedals :)
by Sari
29 Sep 2010, 09:43
Forum: Boutique Stompboxes dissected...
Topic: Fulltone - Plimsoul [traced]
Replies: 54
Views: 32478

Re: Fulltone Plimsoul [traced]

Greg_G wrote:I moved this to the Member's Corner, as it isn't actually a schematic of the Plimsoul... so it's really just a topic for discussion at this time.
Sorry... :oops:
by Sari
29 Sep 2010, 08:03
Forum: Boutique Stompboxes dissected...
Topic: Fulltone - Plimsoul [traced]
Replies: 54
Views: 32478

Re: Fulltone Plimsoul [traced]

how would you describe the sound in terms of frequency response? mid heavy? thick? grainy? etc.... The two different clipping stage sound very different on their own. I tried these out independently, interacting with the other control as well. The "Sustain" part gives a balanced full bodi...
by Sari
28 Sep 2010, 10:54
Forum: Boutique Stompboxes dissected...
Topic: Fulltone - Plimsoul [traced]
Replies: 54
Views: 32478

Re: Fulltone Plimsoul [traced]

Note: a little mistake in the picture - pin 4 of the OA should be connected to ground
by Sari
28 Sep 2010, 09:55
Forum: Boutique Stompboxes dissected...
Topic: Fulltone - Plimsoul [traced]
Replies: 54
Views: 32478

Fulltone - Plimsoul [traced]

Hi guys, Before I start, I must say that all that you are about to read is pure a guesstimation from experimenting by ear, and not a traced circuit... So the other day I had the chance to play with a Plimsoul for a while. I must say that it sounds great and is a far better diode clipper than most. T...
by Sari
09 Sep 2010, 15:11
Forum: Boutique Stompboxes dissected...
Topic: Demeter - Fat Control - Guts, Schematic [traced]
Replies: 63
Views: 30111

Re: Demeter Fat Control midboost/buffer Gutshots [traced]

gilmour_pugliese wrote:Hi! it's possible to substitute the LF442 with a OPA2132 or OPA2107 but having the same sound?
Will probably get a "better" sound in terms of "audio quality" - whether you'd like it or not, is up to your ears to decide :)
by Sari
07 Sep 2010, 08:15
Forum: Boutique Stompboxes dissected...
Topic: Demeter - Fat Control - Guts, Schematic [traced]
Replies: 63
Views: 30111

Re: Demeter Fat Control midboost/buffer Gutshots [traced]

yep.. OK ,got the astimated resistors values- R1- 100K R2- 1M R3- 100K R4- 200K R5- 100K R6- 200K R7- 33K R8- 1K8 R9- 100K R10-100K are we good to go? following the schematic the correct values are: R1- 100K R2- 1M R3- 100K R4- 20K R5- 100K R6- 20K R7- 33K R8- 1K8 R9- 100K R10-100K +1 Spice model c...
by Sari
14 Aug 2010, 08:10
Forum: Boutique Stompboxes dissected...
Topic: Mad Professor Sweet Honey Overdrive [traced]
Replies: 124
Views: 78740

Re: Mad Professor Sweet Honey Overdrive [gutshots] + schematic [traced]

Can some explain the 47k/4n7 pair in parallel at the end of the circuit? Is it some sort of filter? (I've noticed emitting the 4n7 cuts alot the treble, or vice re-versa and the bass is just simply thinner) It is a simple Hi-Pass filter, similar to those you can see prior to the Volume pot on a Mar...
by Sari
09 Jul 2010, 19:04
Forum: Boutique Stompboxes dissected...
Topic: Hermida Audio - Nu-Valve
Replies: 23
Views: 7455

Re: hermida Nu-valve

I have tried several types of Nu-Vistors in the past. the 6CW4 were kinda horrible as gain stages in a distortion circuit - they sound fizzy, somewhat noisy and certainly microphonic. Lower volatage Nu-Vistors worked out much better, but still, to my ears at least, not worth the effort. As followers...
