EDEN VT. 40 BASS AMPLIFIER

chicago_mike · Post by **chicago_mike** » 30 Jun 2012, 15:41

Ladies and gentlemen, cunts and pricks!!

The Eden VT.40 Bass amplifier

chicago_mike · Post by **chicago_mike** » 30 Jun 2012, 15:44

Another good bass amp. This one from the early 90's. Before the WT preamp designed by Russ Allee of Acoutic and A.M.P. fame.

This preamp is the James Demeter preamp..notice the compressor!!!

chicago_mike · Post by **chicago_mike** » 30 Jun 2012, 15:48

PREAMP PCB shots

chicago_mike · Post by **chicago_mike** » 30 Jun 2012, 15:51

more pcb preamp shots.

chicago_mike · Post by **chicago_mike** » 30 Jun 2012, 15:56

THAT chips!!!!!

chicago_mike · Post by **chicago_mike** » 30 Jun 2012, 16:02

chicago_mike · Post by **chicago_mike** » 30 Jun 2012, 16:04

Hmm...this part looks familiar...

Prostheta · Post by **Prostheta** » 30 Jun 2012, 19:04

*cough*fucker*cough*

Duckman · Post by **Duckman** » 30 Jun 2012, 19:56

Oh, Captain, my Captain!

chicago_mike · Post by **chicago_mike** » 30 Jun 2012, 20:20

HA!!

I'll get more shots of her posted later tonight or sunday.

This one was modded before it came to our shop. Its...."interesting"...

Jarno · Post by **Jarno** » 30 Jun 2012, 21:05

That2150 and 2252, studioquality compressor indeed. Nice one!

Prostheta · Post by **Prostheta** » 30 Jun 2012, 21:16

Does that thermostat have the threshold temperature marked on it?

pedalgrinder · Post by **pedalgrinder** » 01 Jul 2012, 11:57

let us know chicago mike when you've finished the entire trace hehehehe

Prostheta · Post by **Prostheta** » 01 Jul 2012, 14:06

I've just completed the poweramp section (same configuration as the Thunderfunk 750A, Eden WD-500, etc.) so I guess this could be done just as easily. Given the commonality of this board in many amps, perhaps a group purchase on a bunch of board might be in order? I would happily represent European posting on that basis.

Just need to confirm that Eden didn't change the basics of the board much from the design I have just been working from, plus it might be a good idea to pool our respective resources to iron out the bugs inherent to this poweramp....specifically the resistors getting too hot and burning the output transistors or vice-versa. It seems somewhat shoddy that these parts seem so susceptible to thermal runaway. I may be wrong as usual though.

Oooooh. Two of the fuckers here!

I want that preamp board. It looks like the centre frequencies for the stacked gyrators are preset at two switched values on the VT.40 as opposed to being variable like on the WT-500/800 and TF 750A et al, so bringing out that valve input stage and pushing the fully adjustable EQ section back in looks preferable.

So what're we doing here? Fixing this to get it out of the door or copying the crying fuck out of it?

chicago_mike · Post by **chicago_mike** » 01 Jul 2012, 17:50

SLOW DOWN!!!!!!![/b][/i][/u]

Concentrate on the thunderfunk.

No tubes or any other crap...until later.

The VT.40 is a passive Fender tonestack. With the switches changing some caps in and out.

chicago_mike · Post by **chicago_mike** » 01 Jul 2012, 18:00

chicago_mike · Post by **chicago_mike** » 01 Jul 2012, 18:05

I have schematics for SWR SM900 and 500 and Eden WT400/800 amps....

I guess, if I feel like a nice guy and not a shmuck, that I could post them......

But it is a shmucky kinda Sunday...

Prostheta · Post by **Prostheta** » 01 Jul 2012, 22:04

Poiple resistors, eh? Noice.
Stop being a dildo and make with the schematics!

Actually, no rush because my priority is the Thunderfucker of course. Need to sort out the PSU side of things since this power amp is so ubiquitous and well, potato-ish.
Personally, I think Eden has far better arrangement for heat management than Thunderfunk. Dave just seems to talk his amps up whereas Eden actually have the balls to back it up. IMO.

pedalgrinder · Post by **pedalgrinder** » 02 Jul 2012, 11:52

See now thats what makes freestompboxes special we get to talk about vibrating penis's and everything!!! Such a special forum

Prostheta · Post by **Prostheta** » 02 Jul 2012, 12:15

As long as they're RoHS. We have to be responsible now.
