Post by noelgrassy »

At $140 they're being very realistic in terms of what we usually see for an OD pedal.

It looks like there's a second transistor, but that doesn't rule it out of being a TS clone
of some sort.

AG, the seller's guts shot was kinda tiny, but they don't goop!

No freakin' swirls or "clown barf" schmegma paint schemes;

South of the Mason-Dixon Line these pedals get there appelations;


If you must help the South rise again, fundage may be sent here;
https://cgi.ebay.com/ws/eBayISAPI.dll?V ... otohosting
Copyright does not protect facts, ideas, systems, or methods of operation, although it may protect the way these things are expressed. US Copyright Office
Top
User avatar
HAR_RJ
Information
Posts: 18
Joined: 11 Sep 2009, 03:42

Post by HAR_RJ »

Does anyone have any info on this circuit? I heard that it's another TS clone and would like to know what changes where made t it.

Thanks,
RJ
Top
User avatar
Greg
Old Solderhand
Information
Posts: 3047
Joined: 03 Nov 2007, 09:35
my favorite amplifier: Tophat Emplexador & Supreme 16.
Completed builds: LOTS..
Location: Australia
Has thanked: 64 times
Been thanked: 163 times

Post by Greg »

noelgrassy wrote:
It looks like there's a second transistor, but that doesn't rule it out of being a TS clone
of some sort.
A standard TS circuit has 2 transistors. (2 buffers).
culturejam wrote: We are equal opportunity exposure artists.
Top
User avatar
tube-exorcist
Resistor Ronker
Information
Posts: 445
Joined: 05 Jul 2007, 20:09
Has thanked: 173 times
Been thanked: 67 times

Post by tube-exorcist »

..
Attachments
Eden Nashville Inside.jpg
"I've noticed there's an inverse relationship between cost of gear and talent. If you need the most expensive gear to get decent tones, then you suck as a player."
Top
User avatar
HAR_RJ
Information
Posts: 18
Joined: 11 Sep 2009, 03:42

Post by HAR_RJ »

That is from above, so what are trying to say?
Top
User avatar
tube-exorcist
Resistor Ronker
Information
Posts: 445
Joined: 05 Jul 2007, 20:09
Has thanked: 173 times
Been thanked: 67 times

Post by tube-exorcist »

That is from above, so what are trying to say?
That you should learn to use the forum software.

The picture "above" has 400 x 300 pixels, If you click on the picture attached you will get a resolution of 800 x 600 pixels. It´s easy to recognize this on the different size of the evilbay watermark in the right lower corner.
"I've noticed there's an inverse relationship between cost of gear and talent. If you need the most expensive gear to get decent tones, then you suck as a player."
Top
User avatar
rs
Breadboard Brother
Information
Posts: 70
Joined: 01 Dec 2007, 14:40
Has thanked: 95 times
Been thanked: 7 times

Post by rs »

The component layout is very similar to Tonepad's Tube Screamer!!!
Top
User avatar
HAR_RJ
Information
Posts: 18
Joined: 11 Sep 2009, 03:42

Post by HAR_RJ »

Thanks. Didn't know what the heck he was talking about. Just needed to know if it was YATS. Thanks again RS!
Top
User avatar
KikoBass
Information
Posts: 6
Joined: 17 Jun 2009, 17:40
Has thanked: 1 time

Post by KikoBass »

Resurrecting the post: anyone has the schematic?
