Post by Pedalpusher »

Here are some gut shots of an E-Wave delay that I have. I don't know the first thing about delay circuits and am trying to find out if this is an analog delay or an analog voiced digital delay. It has a pretty short delay time but I think it works and sounds nice enough for my needs. Sorry for the crappy pics. I know it can't be traced from these pics but I was hoping it would give enough info to get my question answered. Any help is appreciated.
ImageImage[/URL[URL=https://smg.photobucket.com/user/guittguy1/media/20150302_191012_zpsdnhjm0r7.jpg.html]Image[/URL[URL=https://smg.photobucket.com/user/guittguy1/media/20150302_190904_zpsesfl0bdz.jpg.html]Image
Top
User avatar
Pedalpusher
Breadboard Brother
Information
Posts: 89
Joined: 10 Jul 2007, 03:28
Has thanked: 1 time
Been thanked: 2 times

Post by Pedalpusher »

The bigger IC has T2399 on it.
