Post by reb »

I just acquired one of these little drum machines. It's a little hacked up under the hood. Anyone have schem? I struck out with google.
Thanks,
Rob
Top
User avatar
analogguru
Old Solderhand
Information
Posts: 3238
Joined: 26 Jun 2007, 13:58
Been thanked: 123 times
Contact:
Contact analogguru

Post by analogguru »

reb wrote:I just acquired one of these little drum machines.
Any guts ?
It's a little hacked up under the hood.
That doesn´t really matter....
Anyone have schem? I struck out with google.
Thanks,
Rob
... to trace the unit.

Is there a chip inside called M252 or M253 ?

analogguru
There´s a sucker born every minute - and too many of them end up in the bootweak pedal biz.
Top
User avatar
reb
Information
Posts: 34
Joined: 16 Aug 2007, 14:13
Location: Rhode Island
Been thanked: 1 time

Post by reb »

the chip is a M255B1AB
here's some photos.
